Small Case Packaging Machine Cartooning Machine For Coffee Juice
Powder And Medical Gain Bag
HZ-100 Full-automatic cartooning machine Applications:
Automatica Cartoning Machine can pack products into carton box and
seal the box automatically.It's suitable for
food,pharmaceuticals,commodity,cosmetic,sachet,food tray,electrical
component.It also can connect with other machine,like filling
machine,shrink packing machine to be a whole automatic packing
line.
HZ-100 Full-automatic cartooning machine specifications:
| No. | Item | Unit | Description | Remark
|
| 1 | Outward Size of Main Engine | mm | 1300×1000×1550 | not-included synchronous conveyor belt |
| 2 | Total power of cartoning machine | KW | 2.0 | |
| 3 | working voltage | V | 380 or customized | |
| 4 | frequency | HZ | 50 | |
| 5 | Packing speed | carton/min | 65-80cartons/min(appro.) | |
| 6 | Carton specifications | L×W×H mm | (120-160)×80-125)×(20-40) | |
| 7 | Carton paper | g | 350above(White card) | Each square |
| 8 | Startup current | A | 12 | |
| 9 | Full-load operating current | A | 4.5 | |
| 10 | Gas consumption | L/min | 5-20 | |
| 11 | compressed air | Mpa | 0.5-0.8 | |
| 11 | Vacuum pumping capacity | L/min
| 10 | |
| 12 | vacuum degree | Mpa | -0.08 6 | |
| 13 | Total weight | kg | 960 | |
| 14 | Noise | ≤dB | 75 |
|
Machine features:
This set of equipment is a container packing machine, which can
automatically open boxes, load materials, fold ears, fold pages and
insert boxes then output the finished cartons. It is suitable for
various kinds and specifications of carton packaging machines. It
is controlled by PLC microcomputer, with automatic alarm and fault
prompt. It has the characteristics of man-machine interface
control, simple operation and convenient maintenance. The sealing
system has the functions of opening box, loading material, folding,
inserting box, sealing box and so on. The fuselage is made of steel
structure, the outer surface is painted with baking paint, and the
parts touching the color box are all made of high-quality stainless
steel and aluminum. The surface is polished, which has a beautiful
appearance and does not pollute the environment.
Machine accessory list:
| No. | Name | Brand | Made in |
| 1 | The main body | Stainless steel | China |
| 2 | electric elements | Schneider / OMRON | french/japan |
| 3 | pneumatic | AIRTAC | Joint venture |
| 4 | Bearing | Luoyang | China |
| 5 | servo motor | Panasonic | JAPAN |
| 6 | PLC | Siemens? | German |
| 7 | Touch screen | Siemens? | German |
| 8 | Driver | Starlight transmission | China |
FAQ:
Q1: What’s the MOQ of the machines?
The MOQ is 1 set.
Q2: What’s the carton material does the machine use?
3-layer or 5-layer corrugated cartons.
Q3: Is the machine Full-automatic or Semi-automatic?
There’ re both full-automatic and semi-automatic.
Q4: Which model carton sealing machine is suit for our requirement?
Please send us your carton size(carton drawing with dimension on it
is rather helpful),then we can recommend the right machine for you.
Q5: Is the carton sealing machine can be connected with production line?
Yes, it can be connected with the production line or single
operating. Q6:What’s the warranty of the machine?
It’s 1 year warranty except the consuming spare parts Lifetime
maintenance.
Q7: Can you provide customization service for us if we have the special
requirements?
Sure, we can provide customization service for you.
Q8: What’s the added value service of your machine?
We provide free training for your operator and machine maintenance
at our factory in China.Or provide you the technical video for your
reference.
