    80 - 90bags/min Multi Packing Machine Four Sided Sealing Bags Packaging Machine

    Ask Lasest Price
    Brand Name : High Speed Bag Vacuum Packaging Machine-Multi Packing Machine
    Model Number : MRZK12-130C
    Certification : CE
    Supply Ability : 500Pcs/Day
    Delivery Time : 7days
    • Product Details
    • Company Profile

    80 - 90bags/min Multi Packing Machine Four Sided Sealing Bags Packaging Machine

    High Speed Bag Vacuum Packaging Machine-Multi Packing Machine

    PACKAGING PROCESS

    Station 1 Bag feeding Feed many pouches or bags in the bag magazine, our main bag magazine can move up and down, you can feed bags very easily when it moved down, and when it moved up, there are a mechanical arm with two vacuum caps will take bag up and then transmit it to the mechanical gripper on the rotary table.

    Station 2 Date Printing (option)


    Station 3 Opening To open stand pouches from top and bottom with two sets vacuum caps.


    Station 4 Filling Measured its weight by RDKL-4, its weight can be adjusted by the buttons on the screen on the RDKL-4 Electronic scale.There are an opening detection device insert into the open bag or pouch to expanding it and detect if it is open or not.No open no filling no sealing


    Station 5 Sealing To seal the pouch or bag mouth with a couple of heat sealing air bar, the sealing pattern you can option, net or straight lines


    Station 6 Forming and output To make the sealing stable and preventing from wrinkling with a couple of cold press, then output the finished production automatically.


    Applicable scope:
    Agricultural products, daily necessities, food, seasoning, medicine, hardware, electronic products, agriculture and other prefabricated bag products.
    Main optional accessories:
    Material measuring and filling machine, work platform, weight sorting name, material lifting machine, finished product conveyor belt, metal detection machine, spray code machine.



    Technical parameters


    Technical Parameter
    Model NO.MRZK12-130C
    Speed80-90 bags/min
    Width55-100mm
    Length80-180mm
    Air consumption≥0.8m³/min
    Weight3500kg
    Sizs2800*1550*1750mm

    Packaging & Shipping



    Packaging Details
    Standard export carton or plywood case 1pcs/box
    Port
    Shanghai/Ningbo

    Our services


    1.We promise to reply your inquiry relational our product within 24hours.

    2.OEM&ODM service for your unique idea with absolutely convenient.

    3.Experienced foreign trader with professional product knowledge.

    4.Value on business credite , promise to protect your sales data, design,patent information.

    5. Sample & OEM service is available

    6. After-sales service. any question will be settled within 3 days


    FAQ


    Q1. Are you a factory?
    A. Yes, We are professional air compressor factory with more than 10 years experience.

    Q2. How can i get a quotation?
    A. Leave us message with your purchase requemets and we will reply you within one hour on working time. And you may contact us directly by Trade Manager

    Q3. How many design do you have? How can i get your catalog?
    A. We have hundreds of advanced design for your choice , And we have new design every year. Just tell us what kind of product you need and we will provide you plenty of choice,

    Q4. How about your price?
    A. Send me details about what you need, you will get the best price in China. The price is competitive over the world.

    Q5. What's the delivery time and what's the package?
    A. Normally the delivery time is about 25-35 days, Al our products are packed with sea worthy package.
